1. Building the Base

The following sections walk through assembling the robot.

1.1 Lower Base

Mount the LCD display on the base plate using the short spacers. Attach the battery holder with a bolt and nut.

Mount the Arduino Uno on the base plate using the short spacers.

The module has self-adhesive backing. Remove the protective film and attach the module to the base as shown in the image below.

Now attach the medium-length hex spacers to the solar tracker’s base.

1.2 Upper Base

Now attach the sensors to the plate shown below. The plate is symmetrical, so its orientation does not matter here, but note the position of each sensor.

The image below shows the sensors fully mounted.

Now attach the long hex spacers to the sensor plate.

Now attach the plate with all the sensors to the base carrying the LCD display, Arduino Uno, and battery holder.

Finally, insert the four shielding plates beside the photoresistors.

The base is now complete and you can begin the next step.

2. Servo Section

Now begin building the rotating arm that allows the solar panel to rotate and tilt.
Make sure to run through the two setup programs for the two servos before mounting them

 #include <Servo.h>
    Servo lr_servo;//define the name of the servo rotating right and left
    int lr_angle = 90;//set the initial angle to 90 degreeset the initial angle to 90 degree
    const byte lr_servopin = 9;//define the name of the servo rotating upwards and downwards and its control pin

    void setup() {
    lr_servo.attach(lr_servopin);  // set the control pin of the servo
    lr_servo.write(lr_angle);//return to initial angle
    delay(1000);
    }
    void loop() {}

Make sure to choose a pair of thin, short screws.

    #include <Servo.h>
    Servo ud_servo;//define the name of the servo rotating right and left
    int ud_angle = 10;//set the initial angle to 10 degree;keep the solar panels upright to detect the strongest light
    const byte ud_servopin = 10;//define the servo rotating upwards and downwards and its control pin

    void setup() {
    ud_servo.attach(ud_servopin);  // set the control pin of the servo
    ud_servo.write(ud_angle);
    delay(1000);
    }

    void loop() {}

Now that the upper servo has been reset, mount it as shown in the image below.

Now assemble the foot on which the servo section will be mounted.

The image below shows how to screw the servo foot onto the servo section. Remember to tighten it securely.

The entire servo section is now assembled, and you can mount it on the base.

3. Solar Panel Section

To attach the solar panel to the servo section, assemble the parts below and then glue the solar panel onto them.

Now mount the light intensity sensor on the plate before gluing on the solar panel.

After mounting the solar panel section, the assembled and completed project looks like this.

4. Multifunction Code

Below is a code snippet you can upload to your Arduino to enable all the robot’s smart functions. The code adjusts the solar panel towards the point with the most light while also reading temperature, humidity, and light intensity.

/*
  keyestudio sun_follower
  lesson 11
  sun_follower
  http://www.keyestudio.com
*/
#include <Wire.h>
#include <LiquidCrystal_I2C.h>
LiquidCrystal_I2C lcd(0x27, 16, 2);

#include <BH1750.h>
BH1750 lightMeter;

#include <dht11.h>    //include the library code:
dht11 DHT;
#define DHT11_PIN 7  //define the DHT11 as the digital pin 7

#include <Servo.h>
Servo lr_servo;//define the name of the servo rotating right and left
Servo ud_servo;//efine the name of the servo rotating upwards and downwards

const byte interruptPin = 2;  //the pin of button;the corruption is disrupted

int lr_angle = 90;//set the initial angle to 90 degree
int ud_angle = 10;//set the initial angle to 10 degree;keep the solar panels upright to detect the strongest light
int l_state = A0;//define the analog voltage input of the photoresistors
int r_state = A1;
int u_state = A2;
int d_state = A3;
const byte buzzer = 6;  //set the pin of the buzzer to digital pin 6
const byte lr_servopin = 9;//define the control signal pin of the servo rotating right and lef
const byte ud_servopin = 10;//define the control signal pin of the servo rotating clockwise and anticlockwise

unsigned int light; //save the variable of light intensity
byte error = 15;//Define the error range to prevent vibration
byte m_speed = 10;//set delay time to adjust the speed of servo;the longer the time, the smaller the speed
byte resolution = 1;   //set the rotation accuracy of the servo, the minimum rotation angle
int temperature;  //save the variable of temperature
int humidity; //save the variable of humidity

void setup() {
  Serial.begin(9600); //define the serial baud rate
  // Initialize the I2C bus (BH1750 library doesn't do this automatically)
  Wire.begin();
  lightMeter.begin();

  lr_servo.attach(lr_servopin);  // set the control pin of servo
  ud_servo.attach(ud_servopin);  // set the control pin of servo
  pinMode(l_state, INPUT); //set the mode of pin
  pinMode(r_state, INPUT);
  pinMode(u_state, INPUT);
  pinMode(d_state, INPUT);

  pinMode(interruptPin, INPUT_PULLUP);  //the button pin is set to input pull-up mode
  attachInterrupt(digitalPinToInterrupt(interruptPin), adjust_resolution, FALLING); //xternal interrupt touch type is falling edge; adjust_resolution is interrupt service function ISR

  lcd.init();          // initialize the LCD
  lcd.backlight();     //set LCD backlight

  lr_servo.write(lr_angle);//return to initial angle
  delay(1000);
  ud_servo.write(ud_angle);
  delay(1000);

}

void loop() {
  ServoAction();  //servo performs the action
  read_light();   //read the light intensity of bh1750
  read_dht11();   //read the value of temperature and humidity
  LcdShowValue(); //Lcd shows the values of light intensity, temperature and humidity

  //erial monitor displays the resistance of the photoresistor and the angle of servo
  /*Serial.print(" L ");
  Serial.print(L);
  Serial.print(" R ");
  Serial.print(R);
  Serial.print("  U ");
  Serial.print(U);
  Serial.print(" D ");
  Serial.print(D);
  Serial.print("  ud_angle ");
  Serial.print(ud_angle);
  Serial.print("  lr_angle ");
  Serial.println(lr_angle);*/
  //  delay(1000);//During the test, the serial port data is received too fast, and it can be adjusted by adding delay time */
}

/**********the function of the servo************/
void ServoAction(){
  int L = analogRead(l_state);//read the analog voltage value of the sensor, 0-1023
  int R = analogRead(r_state);
  int U = analogRead(u_state);
  int D = analogRead(d_state);
  /**********************system adjusting left and right序**********************/
  //  abs() is the absolute value function
  if (abs(L - R) > error && L > R) { //Determine whether the error is within the acceptable range, otherwise adjust the steering gear
    lr_angle -= resolution;//reduce the angle
    //    lr_servo.attach(lr_servopin);  // connect servo
    if (lr_angle < 0) { //limit the rotation angle of the servo
      lr_angle = 0;
    }
    lr_servo.write(lr_angle);  //output the angle of the servooutput the angle of servo
    delay(m_speed);

  }
  else if (abs(L - R) > error && L < R) { //Determine whether the error is within the acceptable range, otherwise adjust the steering gear
    lr_angle += resolution;//increase the angle
    //    lr_servo.attach(lr_servopin);    // connect servo
    if (lr_angle > 180) { //limit the rotation angle of servo
      lr_angle = 180;
    }
    lr_servo.write(lr_angle);  //output the angle of servo
    delay(m_speed);

  }
  else if (abs(L - R) <= error) { //Determine whether the error is within the acceptable range, otherwise adjust the steering gear
    //    lr_servo.detach();  //release the pin of servo
    lr_servo.write(lr_angle); //output the angle of servo
  }
  /**********************system adjusting up and down**********************/
  if (abs(U - D) > error && U >= D) { //Determine whether the error is within the acceptable range, otherwise adjust the steering gear
    ud_angle -= resolution;//reduce the angle
    //    ud_servo.attach(ud_servopin);  // connect servo
    if (ud_angle < 10) { //limit the rotation angle of servo
      ud_angle = 10;
    }
    ud_servo.write(ud_angle);  //output the angle of servo
    delay(m_speed);

  }
  else if (abs(U - D) > error && U < D) { //Determine whether the error is within the acceptable range, otherwise adjust the steering gear
    ud_angle += resolution;//increase the angle
    //    ud_servo.attach(ud_servopin);  // connect servo
    if (ud_angle > 90) { //limit the rotation angle of servo
      ud_angle = 90;
    }
    ud_servo.write(ud_angle);  //output the angle of servo
    delay(m_speed);

  }
  else if (abs(U - D) <= error) { //Determine whether the error is within the acceptable range. If it is, keep it stable and make no change in angle
    //    ud_servo.detach();  //release the pin of servo
    ud_servo.write(ud_angle);  //output the angle of servo
  }
}

void LcdShowValue() {
  char str1[5];
  char str2[2];
  char str3[2];
  dtostrf(light, -5, 0, str1); //Format the light value data as a string, left-aligned
  dtostrf(temperature, -2, 0, str2);
  dtostrf(humidity, -2, 0, str3);
  //LCD1602 display
  //display the value of the light intensity
  lcd.setCursor(0, 0);
  lcd.print("Light:");
  lcd.setCursor(6, 0);
  lcd.print(str1);
  lcd.setCursor(11, 0);
  lcd.print("lux");

  //display the value of temperature and humidity
  lcd.setCursor(0, 1);
  lcd.print(temperature);
  lcd.setCursor(2, 1);
  lcd.print("C");
  lcd.setCursor(5, 1);
  lcd.print(humidity);
  lcd.setCursor(7, 1);
  lcd.print("%");

  //show the accuracy of rotation
  lcd.setCursor(11, 1);
  lcd.print("res:");
  lcd.setCursor(15, 1);
  lcd.print(resolution);
  /*if (light < 10) {
    lcd.setCursor(7, 0);
    lcd.print("        ");
    lcd.setCursor(6, 0);
    lcd.print(light);
    } else if (light < 100) {
    lcd.setCursor(8, 0);
    lcd.print("       ");
    lcd.setCursor(6, 0);
    lcd.print(light);
    } else if (light < 1000) {
    lcd.setCursor(9, 0);
    lcd.print("      ");
    lcd.setCursor(6, 0);
    lcd.print(light);
    } else if (light < 10000) {
    lcd.setCursor(9, 0);
    lcd.print("      ");
    lcd.setCursor(6, 0);
    lcd.print(light);
    } else if (light < 100000) {
    lcd.setCursor(10, 0);
    lcd.print("     ");
    lcd.setCursor(6, 0);
    lcd.print(light);
    }*/
}

void read_light(){
  light = lightMeter.readLightLevel();  //read the light intensity detected by BH1750
}

void read_dht11(){
  int chk;
  chk = DHT.read(DHT11_PIN);      // read data
  switch (chk) {
    case DHTLIB_OK:
      break;
    case DHTLIB_ERROR_CHECKSUM:   //check and return error
      break;
    case DHTLIB_ERROR_TIMEOUT:    //Timeout and return error
      break;
    default:
      break;
  }
  temperature = DHT.temperature;
  humidity = DHT.humidity;
}

/*********function disrupts service**************/
void adjust_resolution() {
  tone(buzzer, 800, 100);
  delay(10);  //delay to eliminate vibration
  if (!digitalRead(interruptPin)){
    if(resolution < 5){
      resolution++;
    }else{
      resolution = 1;
    }
  }
}
