An incredibly cool Mini Tank Robot — current selection; check compatibility from Keyestudio that offers plenty of entertainment and, just as importantly, learning! You can program it with both Arduino IDE and Mixly. You can also swap different sensors and actuators as modules, so this little robot gives you real value for money! The video below demonstrates just three of the features the robot offers, along with a short video of the building process. You can find all the code examples for the robot — current selection; check compatibility, on our GitHub, accessible here.

Important Information

To program the robot you may need to install a driver on your Windows computer so it can recognise the Arduino Uno when connected. The driver can be downloaded here.

The tank has an 8x16 LED matrix display at the front that you can customise yourself. There is a great website where you can easily draw your design, and the site converts it to hex code that you can use in your Arduino code. You can find the website here.

The tank uses 2x 18650 batteries — current selection; check compatibility that are not included in the package. You also need a CR2032 coin cell battery for the IR remote control. You can buy it here at eBits!

There are two main configurations for the robot. Think of it as getting two robots for the price of one: one with an ultrasonic sensor and photoresistors, and one with flame sensors and a fan. The image below shows the “two” robots

APP

Mini Tank Robot V3 — current selection; check compatibility is equipped with a Bluetooth module so you can control the tank and its many functions from your phone. Both Android and Apple phones can be used. Simply download the app called KeyesRobot.

Google Play Store https://play.google.com/store/apps/details?id=com.keyestudio.keyestudio App Store Open App Store → Search for KeyesRobot → Download the app to your phone

When you open the app, first press the Bluetooth button in the right-hand corner. A menu appears where you can connect to the Mini Tank Robot V3 — current selection; check compatibility. Then select the robot pictured in the middle of the screen. You will now see many functions for controlling the robot. Watch the introductory video if needed.

Building the Tank

The following image sequence shows how to assemble the tank itself. First, assemble the 8x16 LED matrix and screw it onto the acrylic plate.

Building the Tank with an Ultrasonic Sensor and Photoresistors

The following section explains how to set up the robot with the ultrasonic sensor and photoresistors. First, attach the ultrasonic sensor to the bent acrylic plate.



Building the Tank with Flame Sensors and a Fan

The images below show how to switch to the fan and flame sensors. Note that you also need to swap the connecting cables for the other ones included in the package. Do not worry: the cables that fit the photoresistors do not fit the flame sensors.

IR Remote

The following example is based on controlling the robot — current selection; check compatibility using infrared. The package includes a small remote control powered by a small 3V coin cell battery. These are available from your local shop.
The code below will get you moving forwards, backwards, right, and left. However, you must import two libraries into your libraries folder. You can find it under Documents -> Arduino -> libraries.
The two libraries are available here

#include <IRremote.h>
IRrecv irrecv(A2);  //
decode_results results;
long ir_rec;  // used to save the IR value

//Array, used to save data of images, can be calculated by yourself or gotten from modulus tool
unsigned char start01[] = {0x01, 0x02, 0x04, 0x08, 0x10, 0x20, 0x40, 0x80, 0x80, 0x40, 0x20, 0x10, 0x08, 0x04, 0x02, 0x01};
unsigned char front[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x12, 0x09, 0x12, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char back[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x48, 0x90, 0x48, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char left[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x00};
unsigned char right[] = {0x00, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char STOP01[] = {0x2E, 0x2A, 0x3A, 0x00, 0x02, 0x3E, 0x02, 0x00, 0x3E, 0x22, 0x3E, 0x00, 0x3E, 0x0A, 0x0E, 0x00};
unsigned char clear[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
#define SCL_Pin  A5  //set the pin of clock to A5
#define SDA_Pin  A4  //set the data pin to A4

#define ML_Ctrl 4  //define the direction control pin of the left motor as 4
#define ML_PWM 5   //define the PWM control pin of the left motor as 5
#define MR_Ctrl 2  //define the direction control pin of the right sensor as 2
#define MR_PWM 6    //define the PWM control pin of the right motor as 9

void setup() {
  Serial.begin(9600);
  irrecv.enableIRIn();  //initialize the IR reception library

  pinMode(ML_Ctrl, OUTPUT);
  pinMode(ML_PWM, OUTPUT);
  pinMode(MR_Ctrl, OUTPUT);
  pinMode(MR_PWM, OUTPUT);

  pinMode(SCL_Pin, OUTPUT);
  pinMode(SDA_Pin, OUTPUT);
  matrix_display(clear); //Clear screens
  matrix_display(start01);  //display the image of start

}

void loop() {
  if (irrecv.decode(&results)) { //receive the value of IR remote
    ir_rec = results.value;
    String type = "UNKNOWN";
    String typelist[14] = {"UNKNOWN", "NEC", "SONY", "RC5", "RC6", "DISH", "SHARP", "PANASONIC", "JVC", "SANYO", "MITSUBISHI", "SAMSUNG", "LG", "WHYNTER"};
    if (results.decode_type >= 1 && results.decode_type <= 13) {
      type = typelist[results.decode_type];
    }
    Serial.print("IR TYPE:" + type + "  ");
    Serial.println(ir_rec, HEX);
    irrecv.resume();
  }

  switch (ir_rec) {
    case 0xFF629D: Car_front();     break;   //the command to go front
    case 0xFFA857: Car_back();      break;   //the command to go back
    case 0xFF22DD: Car_T_left();    break;   //the command to turn left
    case 0xFFC23D: Car_T_right();   break;   //the command to turn right
    case 0xFF02FD: Car_Stop();      break;   //the command to stop
    case 0xFF30CF: Car_left();      break;   //the command to rotate to left
    case 0xFF7A85: Car_right();     break;   //the command to rotate to right
    default: break;
  }

}

/***************motor works***************/
void Car_front() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 200);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 200);
  matrix_display(front);  //show the image to go front
}

void Car_back() {
  digitalWrite(MR_Ctrl, HIGH);
  analogWrite(MR_PWM, 200);
  digitalWrite(ML_Ctrl, HIGH);
  analogWrite(ML_PWM, 200);
  matrix_display(back);  //show the image to go back
}

void Car_left() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 200);
  digitalWrite(ML_Ctrl, HIGH);
  analogWrite(ML_PWM, 200);
  matrix_display(left);  //show the image to rotate to left
}

void Car_right() {
  digitalWrite(MR_Ctrl, HIGH);
  analogWrite(MR_PWM, 200);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 200);
  matrix_display(right);  //show the image to rotate to right
}

void Car_Stop() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 0);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 0);
  matrix_display(STOP01);  //show the image to stop
}

void Car_T_left() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 255);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 150);
  matrix_display(left);  //show the image to turn left
}

void Car_T_right() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 150);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 255);
  matrix_display(right);  //show the image to turn right
}

//this function is used for a dot matrix
void matrix_display(unsigned char matrix_value[])
{
  IIC_start();  //use the function to start transmitting data
  IIC_send(0xc0);  //select an address
  for (int i = 0; i < 16; i++) //image data have 16 characters
  {
    IIC_send(matrix_value[i]); //data to transmit pictures
  }
  IIC_end();   //end the data transmission of pictures
  IIC_start();
  IIC_send(0x8A);  //show control and select pulse width 4/16
  IIC_end();
}

//the condition that data starts transmitting
void IIC_start()
{
  digitalWrite(SDA_Pin, HIGH);
  digitalWrite(SCL_Pin, HIGH);
  delayMicroseconds(3);
  digitalWrite(SDA_Pin, LOW);
  delayMicroseconds(3);
  digitalWrite(SCL_Pin, LOW);
}

//the sign that transmission of data ends
void IIC_end()
{
  digitalWrite(SCL_Pin, LOW);
  digitalWrite(SDA_Pin, LOW);
  delayMicroseconds(3);
  digitalWrite(SCL_Pin, HIGH);
  delayMicroseconds(3);
  digitalWrite(SDA_Pin, HIGH);
  delayMicroseconds(3);
}

//transmit data
void IIC_send(unsigned char send_data)
{
  for (byte mask = 0x01; mask != 0; mask <<= 1) //ecah character has 8 digits, which is detected one by one
  {
    if (send_data & mask) { //set high or low levels in light of each bit(0 or 1)
      digitalWrite(SDA_Pin, HIGH);
    } else {
      digitalWrite(SDA_Pin, LOW);
    }
    delayMicroseconds(3);
    digitalWrite(SCL_Pin, HIGH); //pull up the clock pin SCL_Pin to end the transmission of data
    delayMicroseconds(3);
    digitalWrite(SCL_Pin, LOW); //pull down the clock pin SCL_Pin to change signals of SDA
  }
}

Ultrasonic Follower

A fun little example that uses the ultrasonic sensor to follow your hand or an object. If the hand or object gets too close, the robot starts backing away. Here is the code, where you can change the desired distances. This is a good way to experiment with ultrasonic sensors and understand how to calculate distances.

/*
  keyestudio Mini Tank Robot V3
  lesson 14
  Ultrasonic follow tank
  http://www.keyestudio.com
*/
#define servoPin 10  //the pin of the servo

#define ML_Ctrl 4  //define define the control pin of the left motor as 4
#define ML_PWM 5   //define the PWM control pin of the left motor as 5
#define MR_Ctrl 2  //define the control pin of the right motor as 2
#define MR_PWM 6   //define the PWM control pin of the right motor as 9
#define Trig 12
#define Echo 13
float distance;

void setup() {
  pinMode(servoPin, OUTPUT);
  pinMode(Trig, OUTPUT);
  pinMode(Echo, INPUT);
  pinMode(ML_Ctrl, OUTPUT);
  pinMode(ML_PWM, OUTPUT);
  pinMode(MR_Ctrl, OUTPUT);
  pinMode(MR_PWM, OUTPUT);
  procedure(0); //set the angle of the servo to 90°
  delay(500); //delay in 500ms
}
void loop() {
  distance = checkdistance();  //distance assign the distance detected by an ultrasonic sensor
  if (distance >= 20 && distance <= 60) //the range to go front
  {
    Car_front();
  }
  else if (distance > 10 && distance < 20)  //the range to stop
  {
    Car_Stop();
  }
  else if (distance <= 10)  //the range to go back
  {
    Car_back();
  }
  else  //or else, stop
  {
    Car_Stop();
  }
}
void Car_front()
{
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 200);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 200);
}
void Car_back()
{
  digitalWrite(MR_Ctrl,HIGH);
  analogWrite(MR_PWM,200);
  digitalWrite(ML_Ctrl,HIGH);
  analogWrite(ML_PWM,200);
}
void Car_left()
{
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 200);
  digitalWrite(ML_Ctrl, HIGH);
  analogWrite(ML_PWM, 200);
}
void Car_right()
{
  digitalWrite(MR_Ctrl, HIGH);
  analogWrite(MR_PWM, 200);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 200);
}
void Car_Stop()
{
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 0);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 0);
}

//a function to control servos
void procedure(byte myangle) {
  int pulsewidth;
  for (int i = 0; i < 5; i++) {
    pulsewidth = myangle * 11 + 500;  //calculate the value of pulse width
    digitalWrite(servoPin, HIGH);
    delayMicroseconds(pulsewidth);   //the time that high level maintains is pulse width
    digitalWrite(servoPin, LOW);
    delay((20 - pulsewidth / 1000));  //The cycle is 20ms
  }
}
//a function to control the ultrasonic sensor
float checkdistance() {
  static float distance;
  digitalWrite(Trig, LOW);
  delayMicroseconds(2);
  digitalWrite(Trig, HIGH);
  delayMicroseconds(10);
  digitalWrite(Trig, LOW);
  distance = pulseIn(Echo, HIGH) / 58.20;  //2*29.1=58.2
  delay(10);
  return distance;
}

Multifunction Tank

Here is an example with many of the cool functions implemented. Some functions are commented out and can be enabled instead if you wish. This implementation lets you control the robot via Bluetooth and access the fan, LED matrix, and much more.
It is important to remove the Bluetooth module when uploading the code below, otherwise upload errors may occur. Reconnect the Bluetooth module afterwards.

/*
  keyestudio Mini Tank Robot V3
  lesson 22
  multiple functions
  http://www.keyestudio.com
*/
#include <IRremote.h>
IRrecv irrecv(A2);  //
decode_results results;
long ir_rec;  //used to save the IR value

//Array, used to save data of images, can be calculated by yourself or gotten from modulus tool
unsigned char start01[] = {0x01, 0x02, 0x04, 0x08, 0x10, 0x20, 0x40, 0x80, 0x80, 0x40, 0x20, 0x10, 0x08, 0x04, 0x02, 0x01};
unsigned char STOP01[] = {0x2E, 0x2A, 0x3A, 0x00, 0x02, 0x3E, 0x02, 0x00, 0x3E, 0x22, 0x3E, 0x00, 0x3E, 0x0A, 0x0E, 0x00};
unsigned char front[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x12, 0x09, 0x12, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char back[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x24, 0x48, 0x90, 0x48, 0x24, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};
unsigned char left[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x44, 0x28, 0x10, 0x00};
unsigned char right[] = {0x00, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x10, 0x28, 0x44, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};

unsigned char Smile[] = {0x00, 0x00, 0x1c, 0x02, 0x02, 0x02, 0x5c, 0x40, 0x40, 0x5c, 0x02, 0x02, 0x02, 0x1c, 0x00, 0x00};
unsigned char Disgust[] = {0x00, 0x00, 0x02, 0x02, 0x02, 0x12, 0x08, 0x04, 0x08, 0x12, 0x22, 0x02, 0x02, 0x00, 0x00, 0x00};
unsigned char Happy[] = {0x02, 0x02, 0x02, 0x02, 0x08, 0x18, 0x28, 0x48, 0x28, 0x18, 0x08, 0x02, 0x02, 0x02, 0x02, 0x00};
unsigned char Squint[] = {0x00, 0x00, 0x00, 0x41, 0x22, 0x14, 0x48, 0x40, 0x40, 0x48, 0x14, 0x22, 0x41, 0x00, 0x00, 0x00};
unsigned char Despise[] = {0x00, 0x00, 0x06, 0x04, 0x04, 0x04, 0x24, 0x20, 0x20, 0x26, 0x04, 0x04, 0x04, 0x04, 0x00, 0x00};
unsigned char Heart[] = {0x00, 0x00, 0x0C, 0x1E, 0x3F, 0x7F, 0xFE, 0xFC, 0xFE, 0x7F, 0x3F, 0x1E, 0x0C, 0x00, 0x00, 0x00};
unsigned char eBits[] = {0x7e, 0x52, 0x52, 0x00, 0x7e, 0x4a, 0x7e, 0x00, 0x7e, 0x00, 0x02, 0x7e, 0x02, 0x5e, 0x52, 0x72
};

unsigned char clear[] = {0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00};

#define SCL_Pin  A5  //set the pin of clock to A5
#define SDA_Pin  A4  //set the data pin to A4

#define ML_Ctrl 4  //define the direction control pin of the left motor as 4
#define ML_PWM 5   //define the PWM control pin of the left motor as 5
#define MR_Ctrl 2  //define the direction control pin of the right sensor as 2
#define MR_PWM 6   //define the PWM control pin of the right motor as 6

char ble_val;      //used to save the Bluetooth value
byte speeds_L = 200; //the initial speed of the left motor is 200
byte speeds_R = 200; // the initial speed of the right motor is 200
String speeds_l, speeds_r; //receive PWM characters and convert them into PWM value

//#define light_L_Pin D3   //define the pin of the left photoresistor
//#define light_R_Pin A1   //define the pin of the right photoresistor
int left_light;
int right_light;

int flame_L = 3; //define the analog port of the left flame sensor to A0
int flame_R = A1; //define the analog port of the right flame sensor to A1

//wire up the line tracking sensor
#define L_pin  11  //left
#define M_pin  7  //middle
#define R_pin  8  //right
int L_val, M_val, R_val, flame_valL, flame_valR;

//the pin of 130 motor
int INA = 12;
int INB = 13;

//#define Trig 12
//#define Echo 13
float distance;//Store the distance values detected by ultrasonic for following

//Store the distance values detected by ultrasonic for obstacle avoidance
int a;
int a1;
int a2;

#define servoPin 10  //servo Pin

bool flag;  // flage invarible, used to enter and exit a mode
void setup() {
  Serial.begin(9600);
  irrecv.enableIRIn();  //Initialize the library of the IR remote

//  pinMode(light_L_Pin, INPUT);
//  pinMode(light_R_Pin, INPUT);

  //define the pins of sensors to INPUT
  pinMode(flame_L, INPUT);
  pinMode(flame_R, INPUT);

//  pinMode(Trig, OUTPUT);
//  pinMode(Echo, INPUT);

  pinMode(ML_Ctrl, OUTPUT);
  pinMode(ML_PWM, OUTPUT);
  pinMode(MR_Ctrl, OUTPUT);
  pinMode(MR_PWM, OUTPUT);

  pinMode(L_pin, INPUT); //set pins of the line tracking sensor to INPUT
  pinMode(M_pin, INPUT);
  pinMode(R_pin, INPUT);

  pinMode(servoPin, OUTPUT);

  pinMode(SCL_Pin, OUTPUT);
  pinMode(SDA_Pin, OUTPUT);

  pinMode(INA, OUTPUT);//set INA to OUTPUT
  pinMode(INB, OUTPUT);//set INB to OUTPUT

  matrix_display(clear);    //clear screens
  matrix_display(start01);  //show start

  procedure(90); //set the angle of the servo to 90°
}

void loop() {
  if (Serial.available()) //if there is data in the serial buffer
  {
    ble_val = Serial.read();
    Serial.println(ble_val);
    switch (ble_val) {
      case 'F': Car_front(); break; //the command to go front

      case 'B': Car_back(); break;  //the command to go back

      case 'L': Car_left(); break;  //the command to turn left

      case 'R': Car_right(); break; //the command to turn right

      case 'S': Car_Stop();  break; //the command to stop

      case 'e': Tracking();  break; //enter the line tracking mode

      case 'f': Confinement(); break;  //enter the confinement mode

//      case 'g': Avoid(); break;  //enter the obstacle avoidance mode

//      case 'h': Follow(); break;  //enter the line tracking mode
//      case 'i': Light_following();  break;  //enter light following mode

      case 'j': Fire(); break;  //enter the mode to put out fire

      case 'c': fan_begin(); break;  //start the fan

      case 'd': fan_stop();  break;  //turn off the fan

      case 'u': speeds_l = Serial.readStringUntil('#'); speeds_L = String(speeds_l).toInt(); break; //start by receiving u, end by receiving characters # and convert into the integer

      case 'v': speeds_r = Serial.readStringUntil('#'); speeds_R = String(speeds_r).toInt(); break; //start by receiving u, end by receiving characters # and convert into the integer
      case 'k': matrix_display(Smile);    break;  //show "smile" face
      case 'l': matrix_display(Disgust);  break;  //show "disgust" face
      case 'm': matrix_display(Happy);    break;  //show "happy" face
      case 'n': matrix_display(Squint);   break;  //show "Sad" face
      case 'o': matrix_display(Despise);  break;  //show "despise" face
      case 'p': matrix_display(Heart);    break;  //show the hearbeat image
      case '1': matrix_display(eBits);    break;  //show the eBits image
      case 'z': matrix_display(clear);    break;  //clear images

      default: break;
    }
  }
  //the following signals are used to print out
  /*if(ble_val == 'x'){
    distance = checkdistance(); Serial.println(distance);
    delay(50);
  }else if(ble_val == 'w'){
    left_light = analogRead(light_L_Pin);
    Serial.println(left_light);
    delay(50);
  }else if(ble_val == 'y'){
    right_light = analogRead(light_R_Pin);
    Serial.println(right_light);
    delay(50);
  }*/


  if (irrecv.decode(&results)) { //receive the value detected by IR remote
    ir_rec = results.value;
    Serial.println(ir_rec, HEX);
    switch (ir_rec) {
      case 0xFF629D: Car_front();   break;   //the command to go front
      case 0xFFA857: Car_back();    break;   //the command  to go back
      case 0xFF22DD: Car_left();    break;   //the command to rotate to left
      case 0xFFC23D: Car_right();   break;   //the command to rotate to right
      case 0xFF02FD: Car_Stop();    break;   //the command to stop
      default: break;
    }
    irrecv.resume();
  }

}

/*****************obstacle avoidance******************/
/*void Avoid()
{
  flag = 0;
  while (flag == 0)
  {
    a = checkdistance();  //set the front distance detected by the ultrasonic sensor to a
    if (a < 20) {//when the front distance is less than 20cm
      Car_Stop();  //robot stops
      delay(500); //delay in 500ms
      procedure(180);  //servo platform turns left
      delay(500); //delay in 500ms
      a1 = checkdistance();  //set the left distance detected by the ultrasonic sensor to a1
      delay(100); //read value

      procedure(0); //servo platform turns right
      delay(500); //delay in 500ms
      a2 = checkdistance(); //set the right distance detected by the ultrasonic sensor to a2
      delay(100); //read value

      procedure(90);  //back to 90°
      delay(500);
      if (a1 > a2) { //the left distance is larger than the right
        Car_left();  //robots turn left
        delay(700);  //turn left for 700ms
      } else {
        Car_right(); //robot turns right
        delay(700);
      }
    }
    else { //if the front distance ≥20cm，robot goes front
      Car_front(); //go front
    }
    // receive the Bluetooth value to exit the loop
    if (Serial.available())
    {
      ble_val = Serial.read();
      if (ble_val == 'S')  //receive S
      {
        flag = 1;  //set flag to 1,exit the loop
        Car_Stop();
      }
    }
  }
}*/

/*******************line tracking****************/
/*void Follow() {
  flag = 0;
  while (flag == 0) {
    distance = checkdistance();  //set the distance value to distance
    if (distance >= 20 && distance <= 60) //20≤ distance ≤60,go front
    {
      Car_front();
    }
    else if (distance > 10 && distance < 20)  //10＜ distance < 20， stop
    {
      Car_Stop();
    }
    else if (distance <= 10)  //distance≤ 10， go back
    {
      Car_back();
    }
    else  //or else, stop
    {
      Car_Stop();
    }
    if (Serial.available())
    {
      ble_val = Serial.read();
      if (ble_val == 'S')
      {
        flag = 1;  //exit the loop
        Car_Stop();
      }
    }
  }
}*/

/****************light following******************/
/*void Light_following() {
  flag = 0;
  while (flag == 0) {
    left_light = analogRead(light_L_Pin);
    right_light = analogRead(light_R_Pin);
    if (left_light > 650 && right_light > 650) //go front
    {
      Car_front();
    }
    else if (left_light > 650 && right_light <= 650)  //turn left
    {
      Car_left();
    }
    else if (left_light <= 650 && right_light > 650) //turn right
    {
      Car_right();
    }
    else  //or else, stop
    {
      Car_Stop();
    }
    if (Serial.available())
    {
      ble_val = Serial.read();
      if (ble_val == 'S') {
        flag = 1;
        Car_Stop();
      }
    }
  }
}*/

/***************put out fire*****************/
void Fire() {
  flag = 0;
  while (flag == 0) {
    //read the analog value of the flame sensor
    flame_valL = analogRead(flame_L);
    flame_valR = analogRead(flame_R);
    if (flame_valL <= 700 || flame_valR <= 700) {
      Car_Stop();
      fan_begin();
    } else {
      fan_stop();
      L_val = digitalRead(L_pin); //read the value of the left sensor
      M_val = digitalRead(M_pin); //read the value of the middle sensor
      R_val = digitalRead(R_pin); //read the value of the right one

      if (M_val == 1) { //the middle one detects black lines
        if (L_val == 1 && R_val == 0) { //if only the left one detects black lines, turn left
          Car_left();
        }
        else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
          Car_right();
        }
        else { //go front otherwise
          Car_front();
        }
      }
      else { //the middle one doesn't detect black lines
        if (L_val == 1 && R_val == 0) { //if only the left one detects black lines, turn left
          Car_left();
        }
        else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
          Car_right();
        }
        else { //stop otherwise
          Car_Stop();
        }
      }
    }
    if (Serial.available())
    {
      ble_val = Serial.read();
      if (ble_val == 'S') {
        flag = 1;
        Car_Stop();
      }
    }
  }
  }

/***************line tracking*****************/
void Tracking() {
  flag = 0;
  while (flag == 0) {
    L_val = digitalRead(L_pin); //read the value of the left sensor
    M_val = digitalRead(M_pin); //read the value of the middle one
    R_val = digitalRead(R_pin); //read the value of the right one
    if (M_val == 1) { //the middle one detects black lines
      if (L_val == 1 && R_val == 0) { //if only the left one detects black lines, turn left
        Car_left();
      }
      else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
        Car_right();
      }
      else { //or else, go front
        Car_front();
      }
    }
    else { //the middle one doesn't detect the black line
      if (L_val == 1 && R_val == 0) { //if only the left one detect the black line,turn left
        Car_left();
      }
      else if (L_val == 0 && R_val == 1) { //if only the right one detects black lines, turn right
        Car_right();
      }
      else { //or else, stop
        Car_Stop();
      }
    }
    if (Serial.available())
    {
      ble_val = Serial.read();
      if (ble_val == 'S') {
        flag = 1;
        Car_Stop();
      }
    }
  }
}

/***************confinement*****************/
void Confinement() {
  flag = 0;
  while (flag == 0) {
    L_val = digitalRead(L_pin); //read the value of the left sensor
    M_val = digitalRead(M_pin); //read the value of the middle one
    R_val = digitalRead(R_pin); //read the value of the right one
    if ( L_val == 0 && M_val == 0 && R_val == 0 ) { //if no sensor detects black lines, go front
      Car_front();
    }
    else { //or else, any the line tracking sensor can go back and turn left
      Car_back();
      delay(700);
      Car_left();
      delay(800);
    }
    if (Serial.available())
    {
      ble_val = Serial.read();
      if (ble_val == 'S') {
        flag = 1;
        Car_Stop();
      }
    }
  }

}


//he function to control the ultrasonic
/*float checkdistance() {
  float distance;
  digitalWrite(Trig, LOW);
  delayMicroseconds(2);
  digitalWrite(Trig, HIGH);
  delayMicroseconds(10);
  digitalWrite(Trig, LOW);
  distance = pulseIn(Echo, HIGH) / 58.20;  // 2*29.1=58.2
  delay(10);
  return distance;
}*/

//the function to control servo
void procedure(int myangle) {
  int pulsewidth;
  pulsewidth = map(myangle, 0, 180, 500, 2000);  //calculate the pulsewith value
  for (int i = 0; i < 5; i++) {
    digitalWrite(servoPin, HIGH);
    delayMicroseconds(pulsewidth);   //the time that high level maintains is pulse width
    digitalWrite(servoPin, LOW);
    delay((20 - pulsewidth / 1000));  //The cycle is 20ms
  }
}

/***************fan rotates*****************/
void fan_begin() {
  digitalWrite(INA, LOW);
  digitalWrite(INB, HIGH);
}

/***************fan stops rotating*****************/
void fan_stop() {
  digitalWrite(INA, LOW);
  digitalWrite(INB, LOW);
}


/***************dot matrix*****************/
///this function is used for the display of dot matrix
void matrix_display(unsigned char matrix_value[])
{
  IIC_start();  //use the function to start transmitting data
  IIC_send(0xc0);  //select an address
  for (int i = 0; i < 16; i++) //image data have 16 characters
  {
    IIC_send(matrix_value[i]); //data to transmit pictures
  }
  IIC_end();   //end the data transmission of pictures
  IIC_start();
  IIC_send(0x8A);  //show control and select pulse width 4/16
  IIC_end();
}

//the condition that data starts transmitting
void IIC_start()
{
  digitalWrite(SDA_Pin, HIGH);
  digitalWrite(SCL_Pin, HIGH);
  delayMicroseconds(3);
  digitalWrite(SDA_Pin, LOW);
  delayMicroseconds(3);
  digitalWrite(SCL_Pin, LOW);
}

//transmit data
void IIC_send(unsigned char send_data)
{
  for (byte mask = 0x01; mask != 0; mask <<= 1) //ecah character has 8 digits, which is detected one by one
  {
    if (send_data & mask) { //set high or low levels in light of each bit(0 or 1)
      digitalWrite(SDA_Pin, HIGH);
    } else {
      digitalWrite(SDA_Pin, LOW);
    }
    delayMicroseconds(3);
    digitalWrite(SCL_Pin, HIGH); //pull up the clock pin SCL_Pin to end the transmission of data
    delayMicroseconds(3);
    digitalWrite(SCL_Pin, LOW); //pull down the clock pin SCL_Pin to change signals of SDA
  }
}

//the sign that transmission of data ends
void IIC_end()
{
  digitalWrite(SCL_Pin, LOW);
  digitalWrite(SDA_Pin, LOW);
  delayMicroseconds(3);
  digitalWrite(SCL_Pin, HIGH);
  delayMicroseconds(3);
  digitalWrite(SDA_Pin, HIGH);
  delayMicroseconds(3);
}

/***************motor runs***************/
void Car_front() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, speeds_R);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, speeds_L);
  matrix_display(front);  //show the image of going front
}

void Car_back() {
  digitalWrite(MR_Ctrl, HIGH);
  analogWrite(MR_PWM, speeds_R);
  digitalWrite(ML_Ctrl, HIGH);
  analogWrite(ML_PWM, speeds_L);
  matrix_display(back);  //show the image of going back
}

void Car_left() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, speeds_R);
  digitalWrite(ML_Ctrl, HIGH);
  analogWrite(ML_PWM, speeds_L);
  matrix_display(left);  //show the image of turning left
}

void Car_right() {
  digitalWrite(MR_Ctrl, HIGH);
  analogWrite(MR_PWM, speeds_R);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, speeds_L);
  matrix_display(right);  //show the image of turning right
}

void Car_Stop() {
  digitalWrite(MR_Ctrl, LOW);
  analogWrite(MR_PWM, 0);
  digitalWrite(ML_Ctrl, LOW);
  analogWrite(ML_PWM, 0);
  matrix_display(STOP01);  //show the stop image
}

Programming with Mixly

As mentioned, you can also program with Mixly, which is more like building with blocks. It is a great introduction to programming. Download and install the program on your computer.

Once you have downloaded the program, make sure to select Arduino UNO as the board.

The image below shows a simple blink program built in Mixly.

On our GitHub, you can find code examples using Mixly for programming. The link is available here.
For a thorough introduction to using Mixly, we suggest reading the following documentation.
