YF-B7 G1/2 Brass Flow Meter – Precise Water Flow Measurement
YF-B7 G1/2 Brass Flowmeter is a high-precision water flow sensor , designed to measure flow rates accurately in the 1-25 L/min range . The sensor is made of high-quality brass , ensuring long service life and corrosion resistance.
The sensor works using a hall effect sensor that generates pulse output based on the flow rate. This makes it suitable for automated water management systems, industrial applications and smart home solutions . It has a wide operating voltage range from 5V to 15V DC , making it compatible with various microcontrollers such as Arduino, Raspberry Pi and STM32 .
Technical specifications
| Specification | Details |
|---|---|
| Product name | YF-B7 G1/2 Brass Flowmeter |
| Material | Messing |
| Water pressure | > 1.75 MPa |
| Operating voltage | DC 5V - 15V |
| Isolationsmodstand | > 100MΩ |
| Accuracy | ±3% (at 1-25 L/min) |
| Flow Puls Characteristics | (11 * Q) Q = L/min ±3% |
| Output Pulse High | > DC 4.7V (ved 5V input) |
| Output Puls Lav | < 0.5V |
| Puls Duty Cycle | 50% ±10% |
| Thread size | G1/2" (1/2 inch) |
| Compatibility | Arduino, Raspberry Pi, ESP8266, STM32 |
Package contents
✔ 1 pc. YF-B7 G1/2 Brass Flowmeter
